SWEDEN YACHTS 340
Specifications
Hull
| LOA | 34 ft |
| LWL | 27.92 ft |
| Beam | 11.5 ft |
| Draft | 6.42 ft |
| Displacement | 12,600 lb |
| Ballast | 5,179.9 lb |
| Hull speed1.34·√LWL | 7.1 kn |
Rig & Sails
| Iforetriangle height | 47.4 ft |
| Jforetriangle base | 14 ft |
| Pmainsail luff | 41.1 ft |
| Emainsail foot | 12.5 ft |
| FLforestay | 14 ft |
| Mainsail | 609.2 sq ft |
| Jib (100%) | 331.8 sq ft |
| Spinnaker | 564.1 sq ft |
About the SWEDEN YACHTS 340
A winged keel version was also available.
Performance
ORC Performance Data(2 certificates)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 24 |
|---|---|---|---|---|---|---|---|---|---|
| 52° | 3.8 | 5.1 | 5.9 | 6.4 | 6.6 | 6.7 | 6.8 | 6.8 | 6.8 |
| 60° | 4.0 | 5.3 | 6.1 | 6.5 | 6.8 | 6.9 | 7.0 | 7.0 | 7.0 |
| 75° | 4.2 | 5.4 | 6.3 | 6.7 | 6.9 | 7.1 | 7.2 | 7.3 | 7.4 |
| 90° | 4.0 | 5.3 | 6.2 | 6.7 | 7.0 | 7.2 | 7.3 | 7.6 | 7.7 |
| 110° | 3.9 | 5.3 | 6.3 | 6.8 | 7.2 | 7.4 | 7.5 | 7.8 | 7.9 |
| 120° | 3.8 | 5.2 | 6.2 | 6.8 | 7.2 | 7.4 | 7.7 | 8.1 | 8.4 |
| 135° | 3.4 | 4.7 | 5.8 | 6.5 | 7.0 | 7.3 | 7.6 | 8.2 | 9.0 |
| 150° | 2.8 | 4.0 | 5.1 | 6.0 | 6.6 | 7.0 | 7.3 | 7.9 | 8.6 |
| Beat VMG | 2.5 | 3.4 | 4.0 | 4.5 | 4.7 | 4.8 | 4.8 | 4.8 | 4.8 |
| Run VMG | 2.4 | 3.5 | 4.4 | 5.2 | 5.9 | 6.4 | 6.8 | 7.4 | 7.9 |
Estimated Value
Low ConfidenceAsking price by model year
9 listings · boat years 1987–1988 · median $56,076
Each dot is one listing · hover for details · dashed red line marks the median · obvious data-entry outliers (top & bottom 2.5%) excluded.
