SOLARIS 40
Specifications
Hull
| LOA | 40.55 ft |
| LWL | 38.39 ft |
| Beam | 13.45 ft |
| Draft | 7.87 ft |
| Displacement | 21,716 lb |
| Ballast | 6,723.3 lb |
| Hull speed1.34·√LWL | 8.3 kn |
Rig & Sails
| Mainsail | 613.54 sq ft |
| Jib (100%) | 462.85 sq ft |
About the SOLARIS 40
Optional shallow keel: draft 2.0m / 6.56 ft. Also available with a 50 hp or 60 hp engine. Sail area (standard sails): - Main: 57 m² / 613.5 ft² - Genoa: 43 m² / 462.8 ft²
The Solaris 40 is a modern fractional sloop designed by Javier Soto Acebal and built by Solaris Yachts (IT), with production records indicating builds starting in 2021. As a relatively new entry in the market, the vessel combines contemporary design principles with a displacement of 21716.0 lb, though comprehensive long-term owner feedback remains limited due to its recent introduction.
- Best for:
- This boat suits coastal cruisers and weekend sailors seeking a modern, performance-oriented package with a comfortable 26.99 comfort ratio, rather than those seeking a proven bluewater pedigree or high-volume resale market.
- Bluewater capability:
- With a capsize ratio of 1.93 and a D/L ratio of 171.35, the hull form suggests moderate offshore stability, but the lack of long-term owner reports and limited production history (2021-present) prevents a definitive assessment of its bluewater durability.
- Comparables:
- Comparable boats include the Beneteau First 40.7 and Hanse 415, as they share similar fractional sloop rigs, beam widths around 13-14 ft, and target the same performance-cruising demographic.
Performance
ORC Performance Data(7 certificates)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 24 |
|---|---|---|---|---|---|---|---|---|---|
| 52° | 4.0 | 5.4 | 6.5 | 7.2 | 7.7 | 7.9 | 8.1 | 8.2 | 8.2 |
| 60° | 4.2 | 5.7 | 6.7 | 7.4 | 7.8 | 8.1 | 8.3 | 8.4 | 8.5 |
| 75° | 4.4 | 6.0 | 7.1 | 7.7 | 8.1 | 8.3 | 8.5 | 8.9 | 9.0 |
| 90° | 4.7 | 6.3 | 7.4 | 8.0 | 8.4 | 8.6 | 8.8 | 9.1 | 9.5 |
| 110° | 4.5 | 6.1 | 7.3 | 8.0 | 8.4 | 8.8 | 9.2 | 9.9 | 10.4 |
| 120° | 4.3 | 5.8 | 7.0 | 7.8 | 8.3 | 8.7 | 9.1 | 10.0 | 11.1 |
| 135° | 3.6 | 5.1 | 6.3 | 7.3 | 7.9 | 8.4 | 8.8 | 9.7 | 10.8 |
| 150° | 3.0 | 4.3 | 5.5 | 6.5 | 7.2 | 7.7 | 8.1 | 8.7 | 9.4 |
| Beat VMG | 2.5 | 3.5 | 4.3 | 4.9 | 5.3 | 5.6 | 5.7 | 5.8 | 5.8 |
| Run VMG | 2.6 | 3.7 | 4.7 | 5.6 | 6.3 | 6.7 | 7.2 | 8.1 | 8.7 |
Market Price
Estimated Cost of Ownership
Based on 40.55ft LOA. Actual costs vary by condition, usage, and local rates.
