SHOGUN 50
Specifications
Hull
| LOA | 50 ft |
| LWL | 46.59 ft |
| Beam | 12.73 ft |
| Draft | 10.83 ft/ 6.56 ft min |
| Displacement | 17,416.52 lb |
| Ballast | 7,936.7 lb |
| Hull speed1.34·√LWL | 9.1 kn |
Rig & Sails
| Mainsail | 807.29 sq ft |
| Jib (100%) | 645.83 sq ft |
| Spinnaker | 2,475.7 sq ft |
About the SHOGUN 50
Extendable bowsprit. Lifting keel with bulb. Ballast above is bulb weight. Sail area: -Main: 75 m² / 807.3 ft² -Self-tacking jib: 60 m² / 645.8 ft² -Code 0: 145 m² / 1,560.8 ft² -Gennaker: 230 m² / 2,457.7 ft²
Performance
ORC Performance Data(2 certificates)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 24 |
|---|---|---|---|---|---|---|---|---|---|
| 52° | 5.3 | 7.1 | 8.2 | 8.8 | 9.1 | 9.3 | 9.4 | 9.6 | 9.6 |
| 60° | 5.6 | 7.5 | 8.7 | 9.2 | 9.4 | 9.7 | 9.9 | 10.1 | 10.2 |
| 75° | 5.9 | 7.8 | 9.0 | 9.6 | 10.0 | 10.3 | 10.6 | 11.0 | 11.2 |
| 90° | 5.7 | 7.6 | 8.9 | 9.6 | 10.3 | 10.9 | 11.3 | 12.0 | 12.5 |
| 110° | 5.3 | 7.3 | 8.8 | 9.7 | 10.6 | 11.2 | 11.8 | 12.9 | 14.1 |
| 120° | 5.0 | 7.0 | 8.7 | 9.7 | 10.6 | 11.5 | 12.4 | 13.8 | 14.8 |
| 135° | 4.4 | 6.4 | 8.1 | 9.3 | 10.3 | 11.5 | 12.7 | 14.5 | 16.8 |
| 150° | 3.7 | 5.3 | 6.8 | 8.2 | 9.2 | 10.1 | 11.2 | 13.8 | 17.0 |
| Beat VMG | 3.4 | 4.6 | 5.5 | 6.0 | 6.2 | 6.4 | 6.5 | 6.7 | 6.6 |
| Run VMG | 3.2 | 4.6 | 5.9 | 7.1 | 8.0 | 8.8 | 9.7 | 12.0 | 14.7 |
Pricing
We don't have market pricing data for the SHOGUN 50 yet. If you own one, help other buyers — what did you pay for it? Reports build a community price estimate over time.
Estimated Cost of Ownership
Based on 50ft LOA. Actual costs vary by condition, usage, and local rates.
Articles & Reviews
Known Issues & Pre-Purchase Inspection
We don't have enough data on the SHOGUN 50yet to publish model-specific findings we'd stand behind — but here's a free general inspection checklist, built from our research into what actually goes wrong on boats of this kind.
Drawn from 7,029 documented issues across 2,391 models, ordered so the areas that most often turn up problems come first.
Own a SHOGUN 50? Reports from owners are what turn this into a model-specific checklist — and they're the reason the boats above it have one.
