REDLINE 41 (2014)
Specifications
Hull
| LOA | 40.7 ft |
| LWL | 35.4 ft |
| Beam | 12.13 ft |
| Draft | 8.2 ft |
| Displacement | 15,100 lb |
| Ballast | 7,231.4 lb |
| Hull speed1.34·√LWL | 8.0 kn |
Rig & Sails
| Iforetriangle height | 53.3 ft |
| Jforetriangle base | 15.51 ft |
| Pmainsail luff | 52.5 ft |
| Emainsail foot | 18.2 ft |
| FLforestay | 15.5 ft |
| Mainsail | 581 sq ft |
| Jib (100%) | 445 sq ft |
| Spinnaker | 702.7 sq ft |
| SA total | 581 sq ft |
About the REDLINE 41 (2014)
Updated version of KING 40 (2001). Mainsail area: 581 sq.ft/53.98 m2 Jib area: 445 sq.ft./41.4 m2 A-Spin area: 1732 sq.ft/ 160.91 m2 Upwind Sail Area: 1011 sq.ft/93.92 m2 Downwind Sail Area: 2313 sq.ft/215 m2
Performance
ORC Performance Data(1 certificate)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 24 |
|---|---|---|---|---|---|---|---|---|---|
| 52° | 4.3 | 5.8 | 6.9 | 7.5 | 7.8 | 7.9 | 8.0 | 8.1 | 8.1 |
| 60° | 4.6 | 6.2 | 7.2 | 7.7 | 7.9 | 8.1 | 8.2 | 8.3 | 8.4 |
| 75° | 4.8 | 6.4 | 7.3 | 7.8 | 8.1 | 8.3 | 8.5 | 8.7 | 8.9 |
| 90° | 4.7 | 6.3 | 7.4 | 7.8 | 8.1 | 8.4 | 8.7 | 9.1 | 9.4 |
| 110° | 5.0 | 6.6 | 7.7 | 8.2 | 8.5 | 8.8 | 9.1 | 9.5 | 10.0 |
| 120° | 4.8 | 6.5 | 7.6 | 8.2 | 8.7 | 9.1 | 9.4 | 10.1 | 10.8 |
| 135° | 4.0 | 5.8 | 7.2 | 8.0 | 8.5 | 9.0 | 9.6 | 11.2 | 12.8 |
| 150° | 3.5 | 4.9 | 6.1 | 7.2 | 7.9 | 8.4 | 8.8 | 9.9 | 12.7 |
| Beat VMG | 2.8 | 3.8 | 4.7 | 5.3 | 5.5 | 5.7 | 5.8 | 5.9 | 5.9 |
| Run VMG | 3.0 | 4.2 | 5.3 | 6.2 | 6.9 | 7.3 | 7.7 | 8.6 | 11.0 |
