SWAN 55 (FRERS)
Specifications
Hull
| LOA | 58.23 ft |
| LWL | 51.77 ft |
| Beam | 16.4 ft |
| Draft | 8.2 ft |
| Displacement | 49,493.78 lb |
| Ballast | 16,600.2 lb |
| Hull speed1.34·√LWL | 9.6 kn |
Rig & Sails
| Iforetriangle height | 62 ft |
| Jforetriangle base | 20.25 ft |
| Pmainsail luff | 50.5 ft |
| Emainsail foot | 20.5 ft |
| Mainsail | 1,023.75 sq ft |
| Jib (100%) | 862.73 sq ft |
| Spinnaker | 2,960.07 sq ft |
About the SWAN 55 (FRERS)
Interior design: Misa Poggi Optional keels: -Shallow: draft - 2.1 m / 6.89 ft -Performance: draft - 3.4 m / 11.15 ft -Centerboard: draft - 2 m / 2.85 m; 6.56ft / 9.35 ft Sail area: -Main: 95.11 m² / 1,024 ft² -Jib: 80.15 m² / 862 ft² -Gennaker: 275 m² / 2,960 ft²
Performance
ORC Performance Data(10 certificates)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 6 | 8 | 10 | 12 | 14 | 16 | 20 |
|---|---|---|---|---|---|---|---|
| 52° | 6.4 | 7.5 | 8.1 | 8.4 | 8.6 | 8.7 | 8.8 |
| 60° | 6.9 | 8.0 | 8.5 | 8.8 | 9.0 | 9.1 | 9.2 |
| 75° | 7.4 | 8.4 | 9.0 | 9.3 | 9.4 | 9.5 | 9.7 |
| 90° | 7.4 | 8.5 | 9.1 | 9.5 | 9.8 | 9.9 | 10.2 |
| 110° | 6.9 | 8.1 | 8.8 | 9.3 | 9.8 | 10.1 | 10.8 |
| 120° | 6.3 | 7.5 | 8.6 | 9.2 | 9.7 | 10.1 | 11.0 |
| 135° | 5.4 | 6.8 | 7.9 | 8.8 | 9.3 | 9.8 | 10.7 |
| 150° | 4.5 | 5.8 | 6.9 | 7.9 | 8.6 | 9.1 | 9.8 |
| Beat VMG | 4.1 | 4.9 | 5.3 | 5.6 | 5.8 | 5.9 | 6.0 |
| Run VMG | 3.9 | 5.0 | 6.0 | 6.8 | 7.4 | 7.8 | 9.0 |
Pricing
We don't have market pricing data for the SWAN 55 (FRERS) yet. If you own one, help other buyers — what did you pay for it? Reports build a community price estimate over time.
Estimated Cost of Ownership
Based on 58.23ft LOA. Actual costs vary by condition, usage, and local rates.
Articles & Reviews
Known Issues & Pre-Purchase Inspection
We don't have enough data on the SWAN 55 (FRERS)yet to publish model-specific findings we'd stand behind — but here's a free general inspection checklist, built from our research into what actually goes wrong on boats of this kind.
Drawn from 7,029 documented issues across 2,391 models, ordered so the areas that most often turn up problems come first.
Own a SWAN 55 (FRERS)? Reports from owners are what turn this into a model-specific checklist — and they're the reason the boats above it have one.
