SWAN 54
Specifications
Hull
| LOA | 54.07 ft |
| LWL | 47.24 ft |
| Beam | 15.58 ft |
| Draft | 8.01 ft |
| Displacement | 48,500 lb |
| Ballast | 20,227.4 lb |
| Material | 54’ 1”16.48 m |
| Hull speed1.34·√LWL | 9.2 kn |
Rig & Sails
| Mainsail | 872.95 sq ft |
| Jib (100%) | 665.21 sq ft |
| Spinnaker | 2,260.42 sq ft |
Accommodation
| Cabins | 3 |
| Berths | 6 |
| Heads | 2 |
| Water | 180.7 L |
| Fuel | 130.8 L |
| CE category | About1 100 000€(2020) |
About the SWAN 54
Interior design: Heini Gustafsson Available with a centerboard and twin rudders. Ballast: 10,150 kg / 22,400 lbs.; draft: 1.4m/3.7m; 4.59ft/12.14ft Displacement above is "light." Sail area: - Main: 81.1 m² / 873 ft² - 100% jib: 61.8 m² / 665 ft² - Spinnaker: 210 m² / 2,260 ft²
Performance
ORC Performance Data(7 certificates)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 24 |
|---|---|---|---|---|---|---|---|---|---|
| 52° | 4.0 | 5.5 | 6.7 | 7.6 | 8.2 | 8.6 | 8.8 | 9.0 | 9.1 |
| 60° | 4.3 | 5.9 | 7.1 | 7.9 | 8.5 | 8.8 | 9.0 | 9.3 | 9.4 |
| 75° | 4.6 | 6.2 | 7.3 | 8.1 | 8.7 | 9.0 | 9.3 | 9.6 | 9.8 |
| 90° | 4.5 | 6.2 | 7.6 | 8.5 | 9.0 | 9.3 | 9.4 | 9.8 | 10.1 |
| 110° | 4.6 | 6.3 | 7.7 | 8.7 | 9.2 | 9.6 | 9.9 | 10.4 | 10.8 |
| 120° | 4.4 | 6.2 | 7.6 | 8.5 | 9.1 | 9.5 | 9.9 | 10.7 | 11.3 |
| 135° | 3.9 | 5.5 | 6.9 | 8.0 | 8.7 | 9.2 | 9.6 | 10.4 | 11.3 |
| 150° | 3.2 | 4.6 | 5.9 | 7.0 | 7.9 | 8.6 | 9.0 | 9.7 | 10.4 |
| Beat VMG | 2.5 | 3.5 | 4.4 | 5.1 | 5.6 | 6.0 | 6.3 | 6.5 | 6.5 |
| Run VMG | 2.8 | 4.0 | 5.1 | 6.0 | 6.8 | 7.4 | 7.9 | 8.7 | 9.3 |
Market Price
Estimated Cost of Ownership
Based on 54.07ft LOA. Actual costs vary by condition, usage, and local rates.
Articles & Reviews
Known Issues & Pre-Purchase Inspection
We don't have enough data on the SWAN 54yet to publish model-specific findings we'd stand behind — but here's a free general inspection checklist, built from our research into what actually goes wrong on boats of this kind.
Drawn from 7,029 documented issues across 2,391 models, ordered so the areas that most often turn up problems come first.
Own a SWAN 54? Reports from owners are what turn this into a model-specific checklist — and they're the reason the boats above it have one.
