SWAN 115
Specifications
Hull
| LOA | 115.48 ft |
| LWL | 107.74 ft |
| Beam | 26.64 ft |
| Draft | 15.42 ft |
| Displacement | 204,000 lb |
| Ballast | 70,547.8 lb |
| Material | 115’ 6”35.2 m |
| Hull speed1.34·√LWL | 13.9 kn |
Rig & Sails
| Jib (100%) | 3,270.07 sq ft |
| Spinnaker | 6,781.26 sq ft |
Accommodation
| Cabins | 7 |
| Berths | 14 |
| Heads | 7 |
| Water | 792.5 L |
| Fuel | 1452.9 L |
| CE category | N/A€ |
About the SWAN 115
Shown here is flush deck version. Draught (lifting keel, optional) Keel up 3.50 m / 11.48 ft Keel down: 5.75 m / 18.86 ft Displacement (light) 95,000 kg (S) 209,000 lbs 92,500 kg (FD) 204,000 lbs Displacement (loaded) 113,387 kg (S) 249,975 lbs 110,600 kg (FD) 243,830 lbs Ballast 32,000 kg 70,547 lbs Engine Scania DI13 070M 331 kW 450 hp Estimated gross tonnage 145 Sail areas Fore triangle 296.5 m2 3191 sq.ft Main sail 348.9 m2 (S) 3755 sq.ft 356 m2 (FD) 3832 sq.ft Jib 303.8 m2 3270 sq.ft Asymmetric spinnaker 630 m2 6781 sq.ft Tank Capacity: Hot water 220 l 58 gal Grey water 700 l 185 gal Black water 700 l 185 gal Battery & Power Sources Service battery 24 V 1440 Ah / 1 h Handling system battery 24 V 720 Ah / 1 h Emergency batteries 24 V 25 Ah + 75 Ah / 20 h Starting batteries 24 V 75 Ah / 20 h Diesel generators 2 x 230 / 400 V 32 kw 3-phase Shore power 230 / 400 V 36 kVA 3-phase
Performance
ORC Performance Data(1 certificate)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 6 | 8 | 10 | 12 | 14 | 16 | 20 |
|---|---|---|---|---|---|---|---|
| 52° | 7.5 | 9.5 | 11.2 | 12.4 | 13.0 | 13.3 | 14.1 |
| 60° | 8.2 | 10.3 | 12.1 | 13.1 | 13.6 | 13.8 | 14.7 |
| 75° | 8.9 | 11.1 | 12.9 | 13.8 | 14.3 | 14.7 | 15.3 |
| 90° | 8.9 | 11.1 | 12.9 | 13.8 | 14.5 | 15.3 | 16.3 |
| 110° | 8.4 | 10.7 | 12.7 | 13.7 | 14.2 | 14.7 | 16.0 |
| 120° | 8.0 | 10.3 | 12.3 | 13.6 | 14.4 | 15.0 | 16.2 |
| 135° | 7.1 | 9.2 | 11.1 | 12.7 | 13.7 | 14.6 | 16.8 |
| 150° | 5.9 | 7.6 | 9.2 | 10.8 | 12.1 | 13.2 | 14.8 |
| Beat VMG | 4.7 | 6.0 | 7.2 | 8.1 | 8.6 | 9.0 | 9.9 |
| Run VMG | 5.1 | 6.6 | 8.0 | 9.3 | 10.5 | 11.4 | 12.7 |
Pricing
We don't have market pricing data for the SWAN 115 yet. If you own one, help other buyers — what did you pay for it? Reports build a community price estimate over time.
Estimated Cost of Ownership
Based on 115.48ft LOA. Actual costs vary by condition, usage, and local rates.
Articles & Reviews
Known Issues & Pre-Purchase Inspection
We don't have enough data on the SWAN 115yet to publish model-specific findings we'd stand behind — but here's a free general inspection checklist, built from our research into what actually goes wrong on boats of this kind.
Drawn from 7,029 documented issues across 2,391 models, ordered so the areas that most often turn up problems come first.
Own a SWAN 115? Reports from owners are what turn this into a model-specific checklist — and they're the reason the boats above it have one.
