STAR (ORIGINAL 1911)
Specifications
Hull
| LOA | 22.66 ft |
| LWL | 15.41 ft |
| Beam | 5.66 ft |
| Draft | 3.3 ft |
| Displacement | 1,900 lb |
| Ballast | 850.1 lb |
| Hull speed1.34·√LWL | 5.3 kn |
About the STAR (ORIGINAL 1911)
The original STAR class boats of 1911 evolved from another smaller boat called the BUG, built in 1906. The the first batch of 22 were built in the winter of 1910-1911 by Isaac Smith at Port Washington NY. Stars continued with the gaff rig until a short Marconi rig became an option in 1920. Measurements are from the original Gardner plans dated Nov. 1910 Francis Sweisguth worked for the firm of William Gardner at this time.
Performance
ORC Performance Data(1 certificate)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 6 | 8 | 10 | 12 | 14 | 16 | 20 |
|---|---|---|---|---|---|---|---|
| 52° | 4.9 | 5.6 | 5.8 | 5.9 | 6.0 | 6.1 | 6.2 |
| 60° | 5.2 | 5.8 | 6.1 | 6.2 | 6.3 | 6.5 | 6.6 |
| 75° | 5.4 | 5.9 | 6.4 | 6.7 | 6.9 | 7.0 | 7.4 |
| 90° | 5.4 | 6.0 | 6.6 | 7.2 | 7.6 | 7.9 | 8.3 |
| 110° | 5.1 | 5.8 | 6.3 | 7.0 | 7.8 | 9.2 | 10.6 |
| 120° | 4.8 | 5.6 | 6.1 | 6.6 | 7.3 | 8.3 | 11.7 |
| 135° | 4.1 | 5.1 | 5.7 | 6.2 | 6.7 | 7.4 | 9.7 |
| 150° | 3.5 | 4.4 | 5.3 | 5.8 | 6.3 | 6.8 | 8.2 |
| Beat VMG | 3.2 | 3.9 | 4.1 | 4.2 | 4.2 | 4.2 | 4.1 |
| Run VMG | 3.0 | 3.9 | 4.7 | 5.4 | 5.9 | 6.4 | 7.6 |
Pricing
We don't have market pricing data for the STAR (ORIGINAL 1911) yet. If you own one, help other buyers — what did you pay for it? Reports build a community price estimate over time.
Estimated Cost of Ownership
Based on 22.66ft LOA. Actual costs vary by condition, usage, and local rates.
Known Issues & Pre-Purchase Inspection
We don't have enough data on the STAR (ORIGINAL 1911)yet to publish model-specific findings we'd stand behind — but here's a free general inspection checklist, built from our research into what actually goes wrong on boats of this kind.
Drawn from 7,029 documented issues across 2,391 models, ordered so the areas that most often turn up problems come first.
Own a STAR (ORIGINAL 1911)? Reports from owners are what turn this into a model-specific checklist — and they're the reason the boats above it have one.
