SANTANA 525
Specifications
Hull
| LOA | 24.58 ft |
| LWL | 18.5 ft |
| Beam | 9.33 ft |
| Draft | 4.25 ft |
| Displacement | 2,400 lb |
| Ballast | 949.9 lb |
| Hull speed1.34·√LWL | 5.8 kn |
Rig & Sails
| Iforetriangle height | 26.5 ft |
| Jforetriangle base | 8.75 ft |
| Pmainsail luff | 29 ft |
| Emainsail foot | 10 ft |
| FLforestay | 8.8 ft |
| Mainsail | 272.5 sq ft |
| Jib (100%) | 115.9 sq ft |
| Spinnaker | 197.1 sq ft |
About the SANTANA 525
Dimensions from builder flyer and owners manual.
Performance
ORC Performance Data(3 certificates)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 24 |
|---|---|---|---|---|---|---|---|---|---|
| 52° | 3.6 | 4.8 | 5.5 | 5.8 | 6.0 | 6.0 | 6.1 | 6.1 | 6.0 |
| 60° | 3.9 | 5.0 | 5.6 | 5.9 | 6.1 | 6.2 | 6.3 | 6.3 | 6.3 |
| 75° | 4.0 | 5.1 | 5.7 | 6.0 | 6.3 | 6.5 | 6.6 | 6.7 | 6.8 |
| 90° | 3.8 | 5.0 | 5.7 | 6.1 | 6.3 | 6.6 | 6.8 | 7.2 | 7.4 |
| 110° | 3.8 | 5.0 | 5.8 | 6.3 | 6.6 | 7.0 | 7.3 | 7.9 | 8.6 |
| 120° | 3.6 | 4.8 | 5.7 | 6.2 | 6.6 | 7.0 | 7.6 | 9.0 | 10.2 |
| 135° | 3.1 | 4.3 | 5.3 | 5.9 | 6.3 | 6.8 | 7.3 | 9.6 | 12.5 |
| 150° | 2.6 | 3.7 | 4.7 | 5.5 | 6.0 | 6.4 | 6.8 | 8.0 | 11.2 |
| Beat VMG | 2.4 | 3.2 | 3.8 | 4.2 | 4.3 | 4.4 | 4.4 | 4.3 | 4.2 |
| Run VMG | 2.2 | 3.2 | 4.1 | 4.8 | 5.4 | 5.9 | 6.2 | 7.0 | 9.7 |
Estimated Value
Limited DataEstimated Cost of Ownership
Based on 24.58ft LOA. Actual costs vary by condition, usage, and local rates.
Known Issues & Pre-Purchase Inspection
11 reported issues across 6 systems for the SANTANA 525, compiled from owner reports in sailing forums and owner-association material.
