SANTANA 22
Specifications
Hull
| LOA | 22.25 ft |
| LWL | 18.75 ft |
| Beam | 7.5 ft |
| Draft | 3.5 ft |
| Displacement | 2,600 lb |
| Ballast | 1,230.1 lb |
| Hull speed1.34·√LWL | 5.8 kn |
Rig & Sails
| Iforetriangle height | 26 ft |
| Jforetriangle base | 8.5 ft |
| Pmainsail luff | 21.8 ft |
| Emainsail foot | 9.9 ft |
| FLforestay | 8.5 ft |
| Mainsail | 227 sq ft |
| Jib (100%) | 110.5 sq ft |
| Spinnaker | 187.9 sq ft |
About the SANTANA 22
The SANTANA 22 is the first production design by Gary Mull. An updated version was still being built in 2010. Also built under license in Australia. (Triton Boat Co.) Dimensions from W.D. Schock Corp. (1966)
Performance
ORC Performance Data(1 certificate)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 6 | 8 | 10 | 12 | 14 | 16 | 20 |
|---|---|---|---|---|---|---|---|
| 52° | 3.9 | 4.6 | 5.1 | 5.4 | 5.6 | 5.7 | 5.7 |
| 60° | 4.1 | 4.8 | 5.3 | 5.5 | 5.7 | 5.8 | 5.9 |
| 75° | 4.2 | 5.0 | 5.4 | 5.7 | 5.8 | 6.0 | 6.2 |
| 90° | 4.4 | 5.2 | 5.6 | 5.9 | 6.0 | 6.1 | 6.5 |
| 110° | 4.4 | 5.3 | 5.7 | 6.0 | 6.3 | 6.5 | 6.8 |
| 120° | 4.3 | 5.2 | 5.6 | 6.0 | 6.3 | 6.6 | 7.0 |
| 135° | 4.0 | 4.8 | 5.4 | 5.8 | 6.0 | 6.4 | 7.0 |
| 150° | 3.4 | 4.3 | 5.0 | 5.5 | 5.8 | 6.1 | 6.7 |
| Beat VMG | 2.6 | 3.1 | 3.5 | 3.8 | 4.0 | 4.1 | 4.0 |
| Run VMG | 3.0 | 3.7 | 4.4 | 5.0 | 5.4 | 5.7 | 6.3 |
