MUSTANG 30
Specifications
Hull
| LOA | 29.53 ft |
| LWL | 23.23 ft |
| Beam | 8.14 ft |
| Draft | 5.61 ft |
| Displacement | 5,754 lb |
| Hull speed1.34·√LWL | 6.5 kn |
About the MUSTANG 30
First yacht designed to the CHS rule (later to become IRC). Originally came standard with a winged keel (as shown in drawing above) which many owners have converted to a deep fin with bulb.
Designed by Paul Handley and built by Harley Raceboats (UK) from 1988–1998, the Mustang 30 is a rare fractional sloop with only 29 hulls produced. Its lightweight displacement of 5754.0 lb and low D/L ratio of 204.92 define it as a performance-oriented cruiser rather than a heavy displacement bluewater vessel.
- Best for:
- This boat suits coastal cruisers and performance-oriented sailors who prioritize speed and handling over heavy offshore comfort, given its low comfort ratio of 21.67 and relatively light displacement.
- Bluewater capability:
- With a capsize ratio of 1.82 and a fin keel, the Mustang 30 is capable of coastal passages but lacks the heavy displacement and full keel stability typically preferred for extended bluewater cruising.
- Comparables:
- Comparable to other late-80s/90s performance cruisers like the Beneteau First 30 or O'Day 30, but with significantly lower production numbers and a distinct fractional rig setup that appeals to racers.
Performance
ORC Performance Data(1 certificate)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 24 |
|---|---|---|---|---|---|---|---|---|
| 52° | 4.5 | 5.4 | 6.0 | 6.3 | 6.6 | 6.7 | 6.8 | 6.8 |
| 60° | 4.8 | 5.6 | 6.2 | 6.5 | 6.7 | 6.9 | 7.0 | 7.1 |
| 75° | 4.9 | 5.8 | 6.3 | 6.6 | 6.9 | 7.1 | 7.4 | 7.5 |
| 90° | 4.8 | 5.8 | 6.5 | 6.8 | 7.1 | 7.3 | 7.6 | 8.0 |
| 110° | 4.8 | 5.8 | 6.5 | 6.9 | 7.2 | 7.6 | 8.3 | 9.0 |
| 120° | 4.6 | 5.6 | 6.3 | 6.8 | 7.1 | 7.5 | 8.3 | 9.7 |
| 135° | 4.0 | 5.1 | 5.9 | 6.5 | 6.8 | 7.2 | 8.0 | 9.1 |
| 150° | 3.4 | 4.4 | 5.3 | 6.0 | 6.5 | 6.8 | 7.5 | 8.3 |
| Beat VMG | 2.9 | 3.6 | 4.1 | 4.5 | 4.7 | 4.8 | 4.9 | 4.8 |
| Run VMG | 3.0 | 3.8 | 4.6 | 5.3 | 5.9 | 6.4 | 7.0 | 7.7 |
