LUDERS 16
Specifications
Hull
| LOA | 26.33 ft |
| LWL | 16.33 ft |
| Beam | 5.75 ft |
| Draft | 4 ft |
| Displacement | 2,950 lb |
| Ballast | 1,600.1 lb |
| Hull speed1.34ยทโLWL | 5.4 kn |
Rig & Sails
| Iforetriangle height | 22.25 ft |
| Jforetriangle base | 5.83 ft |
| Pmainsail luff | 29 ft |
| Emainsail foot | 11 ft |
| FLforestay | 5.8 ft |
| Mainsail | 237.1 sq ft |
| Jib (100%) | 64.9 sq ft |
| Spinnaker | 110.3 sq ft |
About the LUDERS 16
Originally called the Fishers Island L-Class. The very first boats (14) were of conventional planked construction from the Luders Yard for the Fishers Island YC. Most of these were destroyed in a hurricane after the very first year. After World War II orders came, first from the Chicago YC, for a new version, built of molded plywood. It is thought more than 100 of these were built. In the 1960's and 70's, a fiberglass version was built by Continental Plastics Corporation, then by Midwest Marine and Easterly Yachts.
Designed by A. E. Luders and built by Luders Marine Construction (USA), the Luders 16 is a historic fractional sloop with a production run spanning 1933โ1979, resulting in 229 hulls built. This long production history reflects the boat's enduring appeal as a compact, lightweight cruiser, though its age necessitates careful inspection of structural integrity.
- Best for:
- The Luders 16 is ideally suited for coastal cruising and weekend sailing, particularly for single-handers or couples seeking a manageable, lightweight vessel that is easy to trailer and dock. Its fractional sloop rig and modest dimensions make it accessible for novice sailors looking for a low-maintenance entry into sailing.
- Bluewater capability:
- With a displacement of 2950.0 lb and a capsize ratio of 1.61, the Luders 16 is not designed for serious offshore passage-making but is capable of protected coastal and bay sailing. Its light displacement and fin keel prioritize performance in light winds over heavy-weather stability.
- Comparables:
- Comparable boats include the O'Day 19 and the Pearson 19, which share similar fractional sloop rigs and compact footprints from the same era. These vessels are comparable due to their shared role as affordable, trailerable day-sailers with similar beam and draft characteristics.
