LADY HELMSMAN
Specifications
Hull
| LOA | 39.7 ft |
| LWL | 31.1 ft |
| Beam | 8.25 ft |
| Draft | 5.74 ft |
| Displacement | 10,361 lb |
| Ballast | 4,927.7 lb |
| Hull speed1.34·√LWL | 7.5 kn |
Rig & Sails
| Iforetriangle height | 36.25 ft |
| Jforetriangle base | 11.65 ft |
| Pmainsail luff | 41.67 ft |
| Emainsail foot | 12.47 ft |
| FLforestay | 11.7 ft |
| Mainsail | 491.8 sq ft |
| Jib (100%) | 211.2 sq ft |
| Spinnaker | 359 sq ft |
About the LADY HELMSMAN
In the late 1980s a 'GT'-version was offered, with a taller mast, and a modified rudder. The original model but with a taller rig is known as the LADY HELMSMAN II.
Performance
ORC Performance Data(4 certificates)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 6 | 8 | 10 | 12 | 14 | 16 | 20 |
|---|---|---|---|---|---|---|---|
| 52° | 4.8 | 5.8 | 6.4 | 6.6 | 6.8 | 6.9 | 7.0 |
| 60° | 5.1 | 6.1 | 6.7 | 6.9 | 7.0 | 7.1 | 7.2 |
| 75° | 5.2 | 6.3 | 6.9 | 7.2 | 7.3 | 7.4 | 7.5 |
| 90° | 5.2 | 6.3 | 6.9 | 7.3 | 7.5 | 7.7 | 7.9 |
| 110° | 5.1 | 6.4 | 7.1 | 7.5 | 7.8 | 8.0 | 8.3 |
| 120° | 4.9 | 6.1 | 7.0 | 7.5 | 7.8 | 8.1 | 8.6 |
| 135° | 4.2 | 5.4 | 6.4 | 7.1 | 7.5 | 8.0 | 8.8 |
| 150° | 3.5 | 4.6 | 5.6 | 6.5 | 7.1 | 7.5 | 8.3 |
| Beat VMG | 3.1 | 3.9 | 4.3 | 4.5 | 4.6 | 4.7 | 4.8 |
| Run VMG | 3.0 | 4.0 | 4.9 | 5.7 | 6.3 | 6.9 | 7.7 |
