HENDERSON 30
Specifications
Hull
| LOA | 30.83 ft |
| LWL | 28.75 ft |
| Beam | 9.83 ft |
| Draft | 7 ft/ 1.75 ft min |
| Displacement | 3,850 lb |
| Ballast | 1,749.8 lb |
| Hull speed1.34·√LWL | 7.2 kn |
Rig & Sails
| Iforetriangle height | 37.11 ft |
| Jforetriangle base | 11.04 ft |
| Pmainsail luff | 38.17 ft |
| Emainsail foot | 14.43 ft |
| FLforestay | 11 ft |
| Mainsail | 502.3 sq ft |
| Jib (100%) | 204.9 sq ft |
| Spinnaker | 637.6 sq ft |
About the HENDERSON 30
The HENDERSON 30 features a masthead spinnaker with retractable, articulating sprit(prod), and a retractable outboard housing.
Designed by Glenn Henderson and built by SOCA Sailboats in Trinidad from 1997–2000, the Henderson 30 is a rare fractional sloop with only 30 hulls produced. Its lightweight displacement of 3850.0 lb and high SA/D ratio of 31.35 define it as a performance-oriented coastal cruiser rather than a heavy bluewater trawler.
- Best for:
- This boat suits active coastal cruisers and short-handed sailors who prioritize sailing performance and ease of handling over heavy offshore endurance. Its fractional rig and relatively light displacement make it ideal for those seeking a responsive, easy-to-sail package for bay and coastal waters.
- Bluewater capability:
- With a low D/L ratio of 72.33 and a capsize ratio of 2.51, the Henderson 30 is not ideally suited for extended bluewater passages due to its light displacement and narrow beam relative to its length. Owners report significant structural concerns, particularly regarding the keel and deck core, which further limit its offshore credibility without extensive reinforcement.
- Comparables:
- Comparable boats include the Beneteau First 30 and O'Day 302, which share similar fractional sloop rigs and performance-focused designs from the late 1990s. These models offer similar LOA dimensions and target the same market of sailors seeking a balance between speed and manageable size.
Performance
ORC Performance Data(8 certificates)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 24 |
|---|---|---|---|---|---|---|---|---|---|
| 52° | 4.6 | 6.0 | 6.8 | 7.2 | 7.4 | 7.5 | 7.6 | 7.8 | 7.8 |
| 60° | 4.9 | 6.3 | 7.0 | 7.4 | 7.6 | 7.8 | 7.9 | 8.1 | 8.2 |
| 75° | 5.1 | 6.4 | 7.1 | 7.6 | 8.0 | 8.3 | 8.5 | 8.8 | 9.0 |
| 90° | 4.9 | 6.3 | 7.0 | 7.6 | 8.1 | 8.6 | 9.1 | 9.7 | 10.2 |
| 110° | 5.0 | 6.5 | 7.4 | 8.0 | 8.5 | 9.0 | 9.5 | 10.6 | 12.0 |
| 120° | 4.9 | 6.4 | 7.3 | 8.1 | 8.9 | 9.5 | 10.1 | 11.4 | 12.7 |
| 135° | 4.2 | 5.8 | 6.9 | 7.7 | 8.6 | 9.6 | 10.9 | 13.1 | 14.9 |
| 150° | 3.5 | 4.9 | 6.0 | 6.9 | 7.7 | 8.4 | 9.4 | 12.6 | 16.0 |
| Beat VMG | 2.9 | 4.0 | 4.8 | 5.2 | 5.4 | 5.5 | 5.5 | 5.6 | 5.5 |
| Run VMG | 3.0 | 4.2 | 5.2 | 6.0 | 6.7 | 7.3 | 8.1 | 10.9 | 13.8 |
