HANSE 510
Specifications
Hull
| LOA | 52.4 ft |
| LWL | 47.24 ft |
| Beam | 16.11 ft |
| Draft | 7.97 ft |
| Displacement | 36,464.46 lb |
| Hull speed1.34·√LWL | 9.2 kn |
About the HANSE 510
Shallow keel draft: 1.98m / 6.5ft Displacement with shallow keel: 16,940 kg / 37,346 lbs Sail area: - Main: 66 m / 710 ft - Jib: 53 m / 570 ft - Genoa: 62 m / 667 ft - Reacher: 94 m / 1,011 ft - Gennaker: 189 m / 2,034 ft Optional 110 hp engine. Standard interior shown. Four other versions are available.
The Hanse 510 is a modern fractional sloop designed by Berret-Racoupeau and built by Hanse Yachts (GER) in 2023. With a displacement of 36464.46 lb and a comfort ratio of 28.52, it balances performance with cruising comfort, though the exact number of hulls built remains unconfirmed in the source data.
- Best for:
- This vessel suits coastal cruisers and performance-oriented sailors who prioritize modern electronics and fractional rig efficiency, as evidenced by the high prevalence of B&G and Raymarine upgrades in owner reports.
- Bluewater capability:
- With a capsize ratio of 1.95 and a displacement of 36464.46 lb, the Hanse 510 offers moderate offshore stability, though its relatively low D/L ratio of 154.42 suggests it is optimized more for coastal performance than heavy bluewater displacement cruising.
- Comparables:
- Comparable boats include other large fractional sloop cruisers from the early 2020s, such as the Beneteau Oceanis 51.1 or Dufour 51, which share similar fractional rig configurations and focus on interior volume and modern sailing dynamics.
Performance
ORC Performance Data(1 certificate)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 24 |
|---|---|---|---|---|---|---|---|---|---|
| 52° | 4.4 | 6.0 | 7.1 | 7.9 | 8.3 | 8.5 | 8.6 | 8.7 | 8.7 |
| 60° | 4.8 | 6.4 | 7.5 | 8.2 | 8.6 | 8.8 | 8.9 | 9.0 | 9.1 |
| 75° | 5.1 | 6.7 | 7.7 | 8.4 | 8.8 | 9.1 | 9.2 | 9.4 | 9.5 |
| 90° | 5.0 | 6.6 | 7.7 | 8.4 | 8.9 | 9.2 | 9.4 | 9.8 | 10.1 |
| 110° | 4.3 | 5.9 | 7.1 | 8.1 | 8.8 | 9.2 | 9.6 | 10.3 | 10.8 |
| 120° | 4.0 | 5.6 | 6.9 | 8.0 | 8.7 | 9.1 | 9.5 | 10.3 | 11.1 |
| 135° | 3.4 | 4.9 | 6.2 | 7.3 | 8.2 | 8.8 | 9.2 | 10.0 | 10.8 |
| 150° | 2.8 | 4.1 | 5.3 | 6.4 | 7.3 | 8.0 | 8.4 | 9.1 | 9.7 |
| Beat VMG | 2.8 | 3.9 | 4.7 | 5.3 | 5.6 | 5.8 | 5.9 | 6.0 | 6.0 |
| Run VMG | 2.4 | 3.6 | 4.6 | 5.5 | 6.3 | 6.9 | 7.3 | 8.4 | 9.2 |
Estimated Value
Low ConfidenceAsking price by model year
27 listings · boat years 2022–2026 · median $582,768
Each dot is one listing · hover for details · dashed red line marks the median · obvious data-entry outliers (top & bottom 2.5%) excluded.
Estimated Cost of Ownership
Based on 52.4ft LOA. Actual costs vary by condition, usage, and local rates.
Featured YouTube Videos
Articles & Reviews
Known Issues & Pre-Purchase Inspection
We don't have enough data on the HANSE 510yet to publish model-specific findings we'd stand behind — but here's a free general inspection checklist, built from our research into what actually goes wrong on boats of this kind.
Drawn from 7,029 documented issues across 2,391 models, ordered so the areas that most often turn up problems come first.
Own a HANSE 510? Reports from owners are what turn this into a model-specific checklist — and they're the reason the boats above it have one.
Similar Sailboats
Which engine powers your HANSE 510?
We haven't confirmed the engine for this model yet. If you own or know one, tell us — as owners report in, we build an accurate picture over time.
Brands sometimes mentioned for this model: Yanmar — is it one of these?
Already know your engine? Search all engines → to find its exact parts.
Used sails that fit the HANSE 510
Checking eBay for sails sized to this boat's rig…
