GRANADA 24
Specifications
Hull
| LOA | 23.43 ft |
| LWL | 21.26 ft |
| Beam | 8.27 ft |
| Draft | 4.1 ft |
| Displacement | 3,968 lb |
| Ballast | 1,874.1 lb |
| Hull speed1.34·√LWL | 6.2 kn |
Rig & Sails
| Iforetriangle height | 29.52 ft |
| Jforetriangle base | 9.35 ft |
| Pmainsail luff | 25.75 ft |
| Emainsail foot | 8.37 ft |
| FLforestay | 9.4 ft |
| Mainsail | 254.4 sq ft |
| Jib (100%) | 138 sq ft |
| Spinnaker | 234.6 sq ft |
About the GRANADA 24
Diesel inboard available as an option.
Designed by Jørn Hansen and built by Granada Yachts A/S (DEN) from 1974–1977, the Granada 24 is a compact masthead sloop with 200 hulls produced. Its lightweight displacement of 3968.0 lb and fin keel configuration reflect a design philosophy focused on agility and ease of handling rather than heavy offshore stability.
- Best for:
- This boat is best suited for coastal cruisers and weekend sailors who prioritize easy single-handed handling and trailerability over heavy-weather endurance. Its manageable size and light displacement make it ideal for those with limited storage space or who prefer active, responsive sailing.
- Bluewater capability:
- With a low displacement of 3968.0 lb and a capsize ratio of 2.09, the Granada 24 is not recommended for extended bluewater passages due to its light weight and lack of heavy ballast for offshore stability.
- Comparables:
- Comparable boats include the O'Day 23 and Pearson 23, which share similar dimensions and target the same market of entry-level coastal cruisers. These vessels are comparable due to their similar beam, draft, and role as accessible, trailerable daysailers from the mid-1970s.
Performance
ORC Performance Data(1 certificate)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 6 | 8 | 10 | 12 | 14 | 16 | 20 |
|---|---|---|---|---|---|---|---|
| 52° | 4.0 | 4.6 | 5.2 | 5.5 | 5.7 | 5.8 | 5.9 |
| 60° | 4.2 | 4.9 | 5.5 | 5.7 | 5.9 | 6.0 | 6.1 |
| 75° | 4.4 | 5.2 | 5.6 | 5.8 | 6.0 | 6.2 | 6.5 |
| 90° | 4.4 | 5.3 | 5.7 | 6.0 | 6.2 | 6.3 | 6.6 |
| 110° | 4.5 | 5.3 | 5.8 | 6.1 | 6.3 | 6.7 | 7.0 |
| 120° | 4.3 | 5.2 | 5.7 | 6.0 | 6.3 | 6.5 | 7.1 |
| 135° | 3.9 | 4.8 | 5.5 | 5.8 | 6.1 | 6.3 | 6.9 |
| 150° | 3.4 | 4.3 | 5.0 | 5.5 | 5.8 | 6.1 | 6.7 |
| Beat VMG | 2.5 | 3.0 | 3.4 | 3.7 | 3.9 | 4.0 | 4.1 |
| Run VMG | 2.9 | 3.7 | 4.4 | 5.1 | 5.6 | 5.8 | 6.4 |
Pricing
We don't have market pricing data for the GRANADA 24 yet. If you own one, help other buyers — what did you pay for it? Reports build a community price estimate over time.
Estimated Cost of Ownership
Based on 23.43ft LOA. Actual costs vary by condition, usage, and local rates.
Known Issues & Pre-Purchase Inspection
1 reported issues across 1 systems for the GRANADA 24, compiled from owner reports in sailing forums and owner-association material.
Unlock the full inspection report
Thinking of buying a GRANADA 24? This is an in-depth report on the faults this model is known for — so you know exactly what to check when you walk the boat. For the price of a coffee.
- ✓ All 1 specific issues — severity, symptoms & fixes
- ✓ Model-specific pre-purchase inspection checklist
- ✓ Downloadable PDF to take to your surveyor — yours to keep
One-time $2.99 · secure checkout by Stripe · instant access · 30 days online, PDF yours to keep
Similar Sailboats
Which engine powers your GRANADA 24?
We haven't confirmed the engine for this model yet. If you own or know one, tell us — as owners report in, we build an accurate picture over time.
Brands sometimes mentioned for this model: Volvo Penta — is it one of these?
Already know your engine? Search all engines → to find its exact parts.
