ELAN 310
Specifications
Hull
| LOA | 31.33 ft |
| LWL | 28.58 ft |
| Beam | 10.56 ft |
| Draft | 6.23 ft |
| Displacement | 8,267 lb |
| Ballast | 2,138.5 lb |
| Material | 30’ 4”9.25 m |
| Hull speed1.34·√LWL | 7.2 kn |
Rig & Sails
| Iforetriangle height | 40.19 ft |
| Jforetriangle base | 11.75 ft |
| Pmainsail luff | 39.53 ft |
| Emainsail foot | 13.55 ft |
| FLforestay | 11.8 ft |
| Mainsail | 525.4 sq ft |
| Jib (100%) | 236.1 sq ft |
| Spinnaker | 401.4 sq ft |
Accommodation
| Cabins | 2 |
| Berths | 4 |
| Heads | 6 |
| Water | 37 L |
| Fuel | 11.9 L |
| CE category | N/A€ |
About the ELAN 310
HULL LENGTH: 9.25m/30.35' DRAFT: (racing) 2.15m/7.05' BALLAST (racing) 900 kg/1984 lbs.
The Elan 310 is a fractional sloop designed by Rob Humphreys and built by Elan Marine (SVN) between 2009 and 2012. With a displacement of 8267.0 lb and a beam of 10.56 ft, this vessel represents a performance-oriented cruising platform from the late 2000s.
- Best for:
- This boat suits coastal cruisers and active weekend sailors who prioritize sailing performance and modern ergonomics over heavy offshore comfort, given its relatively light displacement and high sail area-to-displacement ratio.
- Bluewater capability:
- While the Elan 310 features a moderate capsize ratio of 2.09 and a fin keel, its low displacement of 8267.0 lb and comfort ratio of 18.82 suggest it is best suited for protected coastal waters rather than heavy offshore passages.
- Comparables:
- Comparable boats include the Beneteau First 31 and the Jeanneau Sun Odyssey 319, as they share similar fractional rig configurations, lightweight hulls, and a focus on responsive handling for short-handed sailing.
Performance
ORC Performance Data(27 certificates)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 24 |
|---|---|---|---|---|---|---|---|---|---|
| 52° | 3.7 | 5.0 | 5.9 | 6.5 | 6.8 | 7.0 | 7.1 | 7.2 | 7.2 |
| 60° | 3.9 | 5.2 | 6.1 | 6.7 | 7.0 | 7.2 | 7.3 | 7.4 | 7.4 |
| 75° | 4.0 | 5.4 | 6.3 | 6.8 | 7.1 | 7.4 | 7.5 | 7.8 | 7.9 |
| 90° | 4.2 | 5.6 | 6.6 | 7.1 | 7.3 | 7.5 | 7.7 | 8.1 | 8.4 |
| 110° | 4.3 | 5.7 | 6.8 | 7.3 | 7.7 | 8.1 | 8.3 | 8.7 | 9.1 |
| 120° | 4.1 | 5.6 | 6.6 | 7.2 | 7.7 | 8.1 | 8.6 | 9.2 | 9.8 |
| 135° | 3.6 | 5.0 | 6.2 | 6.9 | 7.4 | 7.8 | 8.3 | 9.5 | 11.7 |
| 150° | 3.0 | 4.2 | 5.3 | 6.2 | 6.9 | 7.3 | 7.7 | 8.6 | 9.8 |
| Beat VMG | 2.4 | 3.3 | 4.0 | 4.5 | 4.9 | 5.0 | 5.1 | 5.2 | 5.2 |
| Run VMG | 2.6 | 3.7 | 4.6 | 5.4 | 6.1 | 6.7 | 7.1 | 7.9 | 8.7 |
