DELPHIA 40
Specifications
Hull
| LOA | 39.21 ft |
| LWL | 36.25 ft |
| Beam | 12.93 ft |
| Draft | 7.15 ft |
| Shoal Draft | 5.5 ft(1.68 m) |
| Displacement | 18,188 lb |
| Ballast | 6,085.7 lb |
| Material | 39’ 2”11.95 m |
| Hull speed1.34·√LWL | 8.1 kn |
Accommodation
| Cabins | 2 |
| Berths | 4 |
| Heads | 2 |
| Water | 84.5 L |
| Fuel | 55.5 L |
| CE category | About135 000€(2017) |
About the DELPHIA 40
The Delphia 40 is a fractional sloop designed by Andrzej Skrzat and built by Delphia Yachts, with production records indicating a build year of 2003. While the exact total hull count is unspecified in available data, this model represents a specific era of European yacht construction characterized by robust build quality and traditional cruising aesthetics.
- Best for:
- This vessel is well-suited for coastal and offshore cruisers who prioritize comfort and stability, as evidenced by the high frequency of watermaker, solar panel, and wind generator installations among owners. The prevalence of North sails and Garmin electronics upgrades suggests a user base focused on performance sailing and modern navigation.
- Bluewater capability:
- With a displacement of 18188.0 lb and a capsize ratio of 1.97, the Delphia 40 demonstrates strong offshore stability and seaworthiness. The fin keel design and substantial ballast of 6085.7 lb further support its capability for safe passage in heavy weather conditions.
- Comparables:
- Comparable boats from this era include the Hallberg-Rassy 42 and the Beneteau Oceanis 40, which share similar displacement and beam dimensions. These models are comparable due to their shared focus on bluewater capability and fractional rig configurations popular in the early 2000s.
Performance
ORC Performance Data(4 certificates)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 20 | 24 |
|---|---|---|---|---|---|---|---|---|---|
| 52° | 3.8 | 5.1 | 6.1 | 6.8 | 7.2 | 7.4 | 7.5 | 7.6 | 7.7 |
| 60° | 4.1 | 5.4 | 6.4 | 7.0 | 7.4 | 7.6 | 7.8 | 7.9 | 7.9 |
| 75° | 4.2 | 5.6 | 6.6 | 7.2 | 7.5 | 7.8 | 8.0 | 8.2 | 8.3 |
| 90° | 4.1 | 5.5 | 6.6 | 7.3 | 7.7 | 8.0 | 8.1 | 8.4 | 8.7 |
| 110° | 4.1 | 5.6 | 6.8 | 7.5 | 7.9 | 8.2 | 8.6 | 9.0 | 9.3 |
| 120° | 4.0 | 5.5 | 6.6 | 7.3 | 7.8 | 8.2 | 8.5 | 9.3 | 9.9 |
| 135° | 3.5 | 4.9 | 6.0 | 6.9 | 7.5 | 7.9 | 8.3 | 9.0 | 9.9 |
| 150° | 2.9 | 4.1 | 5.2 | 6.2 | 6.9 | 7.4 | 7.8 | 8.4 | 9.1 |
| Beat VMG | 2.4 | 3.4 | 4.1 | 4.6 | 5.0 | 5.3 | 5.4 | 5.5 | 5.4 |
| Run VMG | 2.5 | 3.6 | 4.5 | 5.3 | 6.0 | 6.5 | 6.9 | 7.5 | 8.1 |
