CS 40
Specifications
Hull
| LOA | 39.25 ft |
| LWL | 32.67 ft |
| Beam | 12.67 ft |
| Draft | 6.58 ft |
| Deep keel | 6.83 ft(2.08 m) |
| Shoal Draft | 5.00 ft(1.52 m) |
| Displacement | 17,000 lb |
| Ballast | 7,500.4 lb |
| Hull speed1.34·√LWL | 7.7 kn |
Rig & Sails
| Iforetriangle height | 53 ft |
| Jforetriangle base | 15.5 ft |
| Pmainsail luff | 47.2 ft |
| Emainsail foot | 16.5 ft |
| FLforestay | 15.5 ft |
| Mainsail | 796.2 sq ft |
| Jib (100%) | 395.3 sq ft |
| Spinnaker | 671.9 sq ft |
| SA total | 800.15 sq ft |
About the CS 40
Std. keel: 6.58'/2.01m Tot. SA: 800.15 ft2 /74.33 m2
The CS 40 is a classic Canadian Sailcraft design by Tony Castro, with production records indicating a build year of 1987. As a 39.25 ft LOA masthead sloop with a displacement of 17000.0 lb, it represents a substantial, heavy-displacement cruising platform from the late 1980s.
- Best for:
- This boat is best suited for experienced coastal cruisers and those seeking a comfortable, stable passage-making vessel, given its high comfort ratio of 25.78 and substantial ballast of 7500.4 lb.
- Bluewater capability:
- With a low capsize ratio of 1.97 and a displacement-to-length ratio of 217.65, the CS 40 exhibits strong inherent stability and seakeeping characteristics suitable for offshore passages.
- Comparables:
- Comparable vessels include the Cal 40 and O'Day 38, which share similar displacement ranges and beam dimensions (12.67 ft), offering a balance of interior volume and offshore capability.
Performance
ORC Performance Data(1 certificate)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 6 | 8 | 10 | 12 | 14 | 16 | 20 |
|---|---|---|---|---|---|---|---|
| 52° | 5.3 | 6.3 | 7.0 | 7.2 | 7.4 | 7.4 | 7.5 |
| 60° | 5.7 | 6.7 | 7.2 | 7.4 | 7.6 | 7.7 | 7.7 |
| 75° | 6.0 | 7.0 | 7.4 | 7.6 | 7.8 | 8.0 | 8.2 |
| 90° | 6.0 | 7.0 | 7.4 | 7.7 | 7.9 | 8.2 | 8.6 |
| 110° | 5.5 | 6.7 | 7.4 | 7.7 | 8.1 | 8.3 | 8.7 |
| 120° | 5.4 | 6.6 | 7.3 | 7.7 | 8.0 | 8.4 | 9.0 |
| 135° | 4.9 | 6.0 | 6.9 | 7.4 | 7.8 | 8.1 | 8.9 |
| 150° | 4.2 | 5.3 | 6.2 | 7.0 | 7.4 | 7.7 | 8.4 |
| Beat VMG | 3.5 | 4.1 | 4.6 | 4.9 | 5.1 | 5.2 | 5.3 |
| Run VMG | 3.6 | 4.6 | 5.4 | 6.1 | 6.8 | 7.3 | 7.9 |
Market Price
Estimated Cost of Ownership
Based on 39.25ft LOA. Actual costs vary by condition, usage, and local rates.
Known Issues & Pre-Purchase Inspection
2 reported issues across 2 systems for the CS 40, compiled from owner reports in sailing forums and owner-association material.
