COLUMBIE 66
Specifications
Hull
| LOA | 21.65 ft |
| LWL | 18.7 ft |
| Beam | 8.2 ft |
| Draft | 49.21 ft |
| Displacement | 3,924.23 lb |
| Ballast | 1,962.1 lb |
| Hull speed1.34·√LWL | 5.8 kn |
Rig & Sails
| Mainsail | 118.4 sq ft |
| Jib (100%) | 144.24 sq ft |
| Spinnaker | 301.39 sq ft |
About the COLUMBIE 66
Other builders: - Olsson & Söner, Smögen, Sweden (1978-1979) - Ciplast, Svendborg, Denmark (autumn 1979) - Ulefoss, Norway (1980) Sail area: -Main: 11 m² / 118.4 ft² -#1 Genoa: 13.4 m² / 144.24 ft² -#2 Genoa: 10 m² / 107.64 ft² -#3 Genoa: 7 m² / 75.35 ft² -Storm jib: 3 m² / 32.3 ft² -Spinnaker: 28 m² / 301.39 ft² SA is for mainsail + #1 genoa Headroom applies to the galley area Most were sold as 3/4 kits to be finished by the buyer A few boats had a lower ballast of 760-780 kg (displacement of 1650-1670 kg) MkII (from 1978) had single laminate fiberglass at all through-hulls
Performance
ORC Performance Data(1 certificate)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 6 | 8 | 10 | 12 | 14 | 16 | 20 |
|---|---|---|---|---|---|---|---|
| 52° | 3.8 | 4.5 | 5.0 | 5.3 | 5.5 | 5.6 | 5.7 |
| 60° | 4.0 | 4.7 | 5.2 | 5.5 | 5.7 | 5.8 | 5.9 |
| 75° | 4.2 | 5.1 | 5.5 | 5.7 | 5.8 | 6.0 | 6.2 |
| 90° | 4.4 | 5.2 | 5.6 | 5.9 | 6.2 | 6.3 | 6.5 |
| 110° | 4.4 | 5.2 | 5.6 | 5.8 | 6.1 | 6.4 | 6.8 |
| 120° | 4.2 | 5.0 | 5.5 | 5.7 | 6.0 | 6.3 | 6.8 |
| 135° | 3.7 | 4.5 | 5.2 | 5.5 | 5.8 | 6.1 | 6.6 |
| 150° | 3.2 | 4.0 | 4.8 | 5.3 | 5.6 | 5.8 | 6.4 |
| Beat VMG | 2.5 | 2.9 | 3.3 | 3.6 | 3.9 | 4.0 | 4.0 |
| Run VMG | 2.8 | 3.5 | 4.2 | 4.9 | 5.3 | 5.6 | 6.1 |
Pricing
We don't have market pricing data for the COLUMBIE 66 yet. If you own one, help other buyers — what did you pay for it? Reports build a community price estimate over time.
Estimated Cost of Ownership
Based on 21.65ft LOA. Actual costs vary by condition, usage, and local rates.
Known Issues & Pre-Purchase Inspection
We don't have enough data on the COLUMBIE 66yet to publish model-specific findings we'd stand behind — but here's a free general inspection checklist, built from our research into what actually goes wrong on boats of this kind.
Drawn from 7,029 documented issues across 2,391 models, ordered so the areas that most often turn up problems come first.
Own a COLUMBIE 66? Reports from owners are what turn this into a model-specific checklist — and they're the reason the boats above it have one.
