BAVARIA VISION 46
Specifications
Hull
| LOA | 45.9 ft |
| LWL | 42.09 ft |
| Beam | 13.75 ft |
| Draft | 7.02 ft |
| Displacement | 27,117 lb |
| Ballast | 7,605.9 lb |
| Material | 44’ 11”13.7 m |
| Hull speed1.34·√LWL | 8.7 kn |
Rig & Sails
| Iforetriangle height | 56.43 ft |
| Jforetriangle base | 15.72 ft |
| Pmainsail luff | 54.4 ft |
| Emainsail foot | 20 ft |
| FLforestay | 15.7 ft |
| Mainsail | 1,031.1 sq ft |
| Jib (100%) | 443.5 sq ft |
| Spinnaker | 754 sq ft |
Accommodation
| Cabins | 2 |
| Berths | 4 |
| Heads | 6 |
| Water | 153.2 L |
| Fuel | 55.5 L |
| CE category | About200 000€(2020) |
About the BAVARIA VISION 46
Shallow draft: 1.7m/5.58'
The Bavaria Vision 46 is a fractional sloop designed by Bruce Farr and built by Bavaria Yachts in Germany, with production records indicating a build year of 2011. This model represents a specific iteration in the Vision series, characterized by a displacement of 27117.0 lb and a beam of 13.75 ft, offering a blend of performance and comfort typical of the early 2010s European cruiser market.
- Best for:
- This boat suits coastal cruisers and weekend sailors who prioritize interior volume and ease of handling, as evidenced by the high frequency of bimini, dodger, and bow thruster installations. It is well-suited for couples or small families seeking a comfortable, well-equipped package for inshore and nearshore passages rather than extreme offshore expeditions.
- Bluewater capability:
- With a capsize ratio of 1.83 and a displacement of 27117.0 lb, the Vision 46 offers moderate offshore stability, though its relatively light displacement for its length suggests it is best suited for protected coastal cruising rather than heavy-weather bluewater passages.
- Comparables:
- Comparable boats include the Beneteau Oceanis 46.1 and the Jeanneau Sun Odyssey 44.2, which share similar fractional rig configurations, beamy hull forms, and a focus on interior space over pure racing performance. These models also target the same market segment of owners seeking a balance between sailing performance and residential comfort.
Performance
ORC Performance Data(1 certificate)
Measured performance data from ORC (Offshore Racing Congress) certificates.
Polar Diagram
Boat speed (kn) vs. true wind angle. Source: ORC
Racing Ratings
Triple Number
ORC Measured
Sail Areas (ORC)
Speed Table (kn)
| TWA \ TWS | 6 | 8 | 10 | 12 | 14 | 16 | 20 |
|---|---|---|---|---|---|---|---|
| 52° | 5.1 | 6.2 | 7.0 | 7.6 | 7.9 | 8.1 | 8.2 |
| 60° | 5.5 | 6.5 | 7.4 | 7.9 | 8.2 | 8.4 | 8.5 |
| 75° | 5.8 | 6.9 | 7.7 | 8.1 | 8.4 | 8.7 | 9.0 |
| 90° | 5.7 | 6.9 | 7.7 | 8.2 | 8.5 | 8.8 | 9.5 |
| 110° | 5.1 | 6.3 | 7.3 | 8.0 | 8.4 | 8.7 | 9.4 |
| 120° | 4.8 | 6.0 | 6.9 | 7.7 | 8.2 | 8.5 | 9.2 |
| 135° | 4.1 | 5.3 | 6.2 | 7.1 | 7.8 | 8.2 | 8.9 |
| 150° | 3.5 | 4.6 | 5.5 | 6.4 | 7.2 | 7.8 | 8.6 |
| Beat VMG | 3.2 | 4.0 | 4.6 | 5.0 | 5.4 | 5.5 | 5.5 |
| Run VMG | 3.0 | 4.0 | 4.9 | 5.7 | 6.5 | 7.2 | 8.2 |
Estimated Value
Medium ConfidenceAsking price by model year
33 listings · boat years 1996–2022 · median $183,600
Each dot is one listing · hover for details · dashed red line marks the median · obvious data-entry outliers (top & bottom 2.5%) excluded.
Estimated Cost of Ownership
Based on 45.9ft LOA. Actual costs vary by condition, usage, and local rates.
Featured YouTube Videos
Articles & Reviews
Known Issues & Pre-Purchase Inspection
7 reported issues across 6 systems for the BAVARIA VISION 46, compiled from owner reports in sailing forums and owner-association material.
