ATLANTIC 23 (GADE)
Specifications
Hull
| LOA | 23.29 ft |
| LWL | 19.09 ft |
| Beam | 8.2 ft |
| Draft | 5.25 ft/ 1.15 ft min |
| Displacement | 2,205 lb |
| Ballast | 661.1 lb |
| Hull speed1.34·√LWL | 5.9 kn |
Rig & Sails
| Mainsail | 99.03 sq ft |
| Jib (100%) | 86.11 sq ft |
| Spinnaker | 430.56 sq ft |
About the ATLANTIC 23 (GADE)
Mainsail: 9.2 m² Jib: 8.0 m² Genoa: 18.0 m² Spinnaker: 40 m² Alternate fractional rig: Mainsail: 10.8 m² Jib: 8.0 m² Genoa: 14.5 m²
Designed by Gade and built by Gade Marine Plastics (GER), the Atlantic 23 is a compact masthead sloop with a production run of 70 hulls in 1976. Its lightweight displacement of 2205.0 lb and fin keel configuration reflect a design philosophy focused on agility and ease of handling rather than heavy offshore stability.
- Best for:
- This boat suits coastal cruisers and weekend sailors who prioritize easy single-handed handling and trailerability over heavy-weather performance. Its small footprint and light weight make it ideal for owners with limited storage space or those seeking a manageable first sailboat.
- Bluewater capability:
- With a low displacement of 2205.0 lb and a capsize ratio of 2.52, the Atlantic 23 is not recommended for extended bluewater passages due to its light weight and limited ballast ratio of 30%. Its design is optimized for protected waters and short coastal hops rather than open ocean endurance.
- Comparables:
- Comparable boats include the Catalina 22 and O'Day 23, as they share similar LOA dimensions and target the same entry-level coastal cruising market. Like these contemporaries, the Atlantic 23 offers a simple masthead sloop rig that is easy to maintain and sail for novice crews.
Performance
Pricing
We don't have market pricing data for the ATLANTIC 23 (GADE) yet. If you own one, help other buyers — what did you pay for it? Reports build a community price estimate over time.
Estimated Cost of Ownership
Based on 23.29ft LOA. Actual costs vary by condition, usage, and local rates.
Known Issues & Pre-Purchase Inspection
1 reported issues across 1 systems for the ATLANTIC 23 (GADE), compiled from owner reports in sailing forums and owner-association material.
